TRILUX Lunexo D1 CDP-I 4400

The smarter light for more comfort

Luminaire type
Exclusive rectangular surface-mounted LED luminaire with rounded corners and visible light edge.

For innovative and prestigious office lighting.

Mounting methods
Surface-mounted luminaire for ceiling mounting in indoor rooms. For single luminaire applications.

Optical system
With inner CDP-I microprismatics. Frosted PMMA cover with lateral light emission edge. Soft light effect with complete glare illumination. VDU workstation-compliant in accordance with 12464-1.

LED system
Luminaire luminous flux 4200 lm, connected load 46,00 W, luminous efficiency of luminaire 91 lm/W. Light colour warm white, correlated colour temperature (CCT) 3000 K, general colour rendering index (CRI) Ra > 80. Mean rated service life L80(tq 25 °C) = 70,000 h, mean rated service life L85(tq 25 °C) = 50,000 h.

Luminaire body
Luminaire body of extruded aluminium profile. End caps of die-cast aluminium. Surface is solvent-free powder-coated silver-grey (RAL 9006). Dimensions (L x W): 1200 mm x 200 mm, luminaire height 49 mm. Permissible ambient temperature (ta): -20 °C - +25 °C.

Electrical version
With electronic transformer, digitally dimmable (DALI). Number of occupied DALI devices: 1. The luminaire complies with fundamental requirements of applicable EU regulations and product safety legislation and bears the CE symbol. The luminaire is also ENEC-certified by an independent testing authority.
